Mixing tips are essential precision instruments designed for optimal blending of two-component dental materials in modern dental practice. Our EvenDent Universal Mixing Tips feature advanced static mixing technology that ensures consistent, homogeneous mixing of impression materials, temporary cements, composites, and other dental compounds with superior efficiency and minimal material waste.
Product Highlights
• Specialized Models – Complete range from all dental impression and mixing applications
• Precision Caliber Design – Upper calibers from 1mm to 8.5mm with standardized 10-14mm lower calibers for optimal flow control
• Professional Color Coding – Industry-standard color combinations for instant material identification and application matching
• Dual Mixing Ratios – Available in 1:1 and 1:10 ratios for diverse clinical requirements from temporary cements to crown materials
• Optimized Length Options – Tube lengths from 22mm to 75mm designed for specific viscosity and access requirements
• Bulk Professional Packaging – 50 pieces per bag, 50 bags per carton for efficient inventory management
Specifications
| Parameter | Details |
|---|---|
| Item | Dental Impression Mixing Tips |
| Model | E50011 |
| Material | Medical Grade Polypropylene |
| Mixing Ratios | 1:1, 1:10 |
| Upper Caliber Range | 1mm – 8.5mm |
| Lower Caliber | 10mm – 14mm |
| Tube Length Range | 22mm – 75mm |
| Total Length Range | 37mm – 89mm |
| Color Options | Yellow+White, Green+White, Pink+White, Purple+White, Blue+Orange, Blue+White, Brown+White, Brown+Black |
| Package Configuration | 50 pieces per bag, 50 bags per carton |
| Carton Weight | 3KG – 11.5KG (varies by model) |
Popular Model Specifications
| Model | Color Combination | Tube Length | Upper Caliber | Total Length | Mixing Ratio | Application |
|---|---|---|---|---|---|---|
| M-01 | Yellow+White | 51mm | 3.5mm | 70mm | 1:1 | Light body impressions |
| M-02 | Green+White | 70mm | 5mm | 89mm | 1:1 | Medium viscosity materials |
| M-03 | Pink+White | 65mm | 5mm | 83mm | 1:1 | Heavy body impressions |
| M-05 | Purple+White | 75mm | 8.5mm | 89mm | 1:1 | Extra heavy materials |
| M-10 | Blue+Orange | 58mm | 1mm | 78mm | 1:10 | Crown & bridge materials |
| M-15 | Brown+White | 25mm | 1mm | 40mm | 1:1 | Temporary cements |
Technical Advantages
Our mixing tips utilize advanced static mixing technology that creates optimal shear forces and extensional flow patterns. The precision-engineered internal elements ensure complete material homogenization through a series of splitting, rotating, and folding actions. This sophisticated mixing process eliminates air entrapment while maintaining consistent viscosity throughout the mixed material.
The streamlined design reduces back-pressure during dispensing, allowing for smoother material flow and more comfortable operation. The transparent construction enables visual confirmation of proper mixing, while the secure locking mechanism prevents material leakage and cross-contamination. Each tip undergoes rigorous quality testing to ensure dimensional accuracy and mixing performance consistency.
Application Scenarios
Light Body Impressions (M-01, M-11, M-12) – Yellow+White and Blue+White models with precise 1mm-3.5mm upper calibers for detailed final impressions and wash techniques
Medium to Heavy Body Materials (M-02, M-03) – Green+White and Pink+White models featuring 5mm upper calibers for consistent mixing of medium and heavy viscosity impression materials
Extra Heavy Applications (M-05) – Purple+White model with 8.5mm upper caliber specifically designed for putty consistency and bulk impression materials
Crown & Bridge Procedures (M-10) – Blue+Orange model with 1:10 mixing ratio optimized for crown and bridge impression materials requiring precise catalyst ratios
Temporary Cement Applications (M-15, M-14, M-17) – Brown combination models with compact 22-25mm tube lengths for precise temporary cement placement in confined spaces
Instructions for Use
- Preparation – Select appropriate mixing tip based on material viscosity and mixing ratio requirements
- Attachment – Securely attach mixing tip to cartridge or dispensing gun until fully seated and locked
- Priming – Dispense small amount of material to ensure proper flow and eliminate air bubbles
- Application – Maintain steady pressure for consistent material flow during procedure
- Disposal – Remove and dispose of mixing tip immediately after use according to clinical waste protocols
Cautions
• Single Use Only – Never reuse mixing tips to prevent cross-contamination and ensure optimal performance
• Proper Storage – Store in clean, dry environment away from direct sunlight and extreme temperatures
• Material Compatibility – Verify compatibility with specific dental materials before use
Storage
Store mixing tips in original packaging at room temperature (15-25°C) in a clean, dry environment. Protect from direct sunlight, moisture, and extreme temperature fluctuations. Maintain sterile packaging integrity until ready for use. Do not store near chemicals or solvents that may compromise material properties.
Technical FAQ
Q1: How do I select the correct model for my specific application?
A1: Choose based on material viscosity and application: M-01 (3.5mm) for light body, M-02/M-03 (5mm) for medium/heavy body, M-05 (8.5mm) for putty, M-10 for crown & bridge (1:10 ratio), and M-15/M-14/M-17 for temporary cements.
Q2: What do the color combinations indicate?
A2: Color coding follows industry standards: Yellow+White for light materials, Green+White for medium viscosity, Pink+White for heavy body, Purple+White for extra heavy, Blue combinations for crown & bridge, and Brown combinations for temporary cements.
Q3: What is the difference between 1:1 and 1:10 mixing ratios?
A3: 1:1 ratio (most models) provides equal parts mixing for standard impression materials, while 1:10 ratio (M-10) is specifically designed for crown & bridge materials requiring precise catalyst proportions.
Q4: How does tube length affect performance?
A4: Shorter tubes (22-25mm) like M-15/M-17 are ideal for temporary cements in confined spaces, while longer tubes (65-75mm) like M-02/M-05 provide better mixing for viscous impression materials.
Q5: What is the significance of upper and lower caliber measurements?
A5: Upper caliber (1-8.5mm) determines material flow rate and application precision, while standardized lower caliber (10-14mm) ensures universal cartridge compatibility across all models.
Order FAQ
Q1: What is the standard package configuration?
A1: All models come in professional bulk packaging of 50 pieces per bag, with 50 bags per carton (2,500 pieces total per carton). This configuration ensures efficient inventory management for busy practices.
Q2: Can I order mixed model assortments?
A2: Yes, we offer custom assortment packages combining different models based on your practice needs. Contact our sales team to create a personalized mix of M-01 through M-17 models.
Q3: What are the carton weights for shipping calculations?
A3: Carton weights vary by model from 3KG (compact models like M-15/M-17) to 11.5KG (larger models like M-05). We provide exact shipping weights for accurate freight calculations.
Q4: Do you offer samples of specific models before bulk ordering?
A4: Absolutely! We provide sample packs containing 5-10 pieces of any specific model so you can test compatibility with your materials and dispensing systems before committing to full cartons.
Q5: What is the minimum order quantity for each model?
A5: Minimum order is one bag (50 pieces) per model. For volume pricing, full carton orders (50 bags) receive significant discounts and reduced per-unit costs.
